Single phase two wire energy meter

Main Features
●  Energy Measurement
Total and time-sharing forward active & reactive energy measurement
Total and time-sharing reverse active & reactive energy measurement
Save last one to sixteen months energy data
●  TOU
4tariffs, Measures active energies in TOU or step tariffs with standard DLMS
support
●  RS-485 serial interface
Support IEC62056(DLMS/COSEM) protocol
●  LCD display
Number of digits value field Up to 7
Digit size 4x10mm

Technical parameters:
Electrical parameters:
Voltage
Nominal voltage Un  230V
Extended operating voltage range  80%~115%Un
Limited voltage  70%~120%Un
Frequency
Nominal frequency fn   60Hz
tolerance   5%
Current
Basic current(Ib)   10A
Maximum current(Imax)   100A
Starting current(Ist)   30mA
Active energy constant   1000imp/kWh
Measurement Accuracy
Active energy to IEC62053‐21   Class1.0
Reactive energy to IEC62053‐23  Class2.0
Power Consumption
Power consumption in Voltage circuit   <2W  <8VA
Power consumption in current circuit   <1VA
Temperature range
Operation meter  25℃ to+70℃
Storage  40℃ to+85℃
